PONDMASTER HY-DRIVE WATER PUMPS are rugged, powerful and efficient. The compact size makes it ideal to use in larger ponds, skimmers, waterfalls or anywhere that space is tight. All pumps come with a full set of fittings and include a free pump bag for extra pump protection.
@@@@@@Product Features
• Powerful, Efficient Hybrid Magnetic/Direct Drive Motor
• Energy-Efficient to Reduce Operating Cost
• Whisper-Quiet Operation
• High-Efficiency Vortex Impeller
• Convenient Carry Handle
• Includes Extra Large Clog Resistant Filter Screen
• Oil-Free / Fish Safe
• Continuous Duty Operation
• 20’ Power Cord with Grounded Plug
• In-line and Submersible Operation
• 1900, 2550, 4850 and 6600 - 1 1/2” Female Threaded Inlet and Male Threaded Outlet
• 7600 - 2” Female Threaded Inlet and 1 1/2" Male Threaded Outlet
• 3 Year Limited Warranty
@@@@@@
Specifications
1900 GPH – ITEM# 20210 Max. Watts/Amps 93/.78 Volts: 120 / 60Hz Shutoff 10' Dimensions (L x W x H) 9.0" x 4.25" x 6.75" Included Fittings: (2) 1 1/2" Couplings, (2) 1 1/2" Stepped Barbs and Swivel Joint Connector | 2550 GPH – ITEM# 20215 Max. Watts/Amps 147/1.25 Volts: 120 / 60Hz Shutoff 1 1' 5" Dimensions (L x W x H) 9.0" x 4.25" x 6.75" Included Fittings: (2) 1 1/2" Couplings, (2) 1 1/2" Stepped Barbs and Swivel Joint Connector |
4850 GPH – ITEM# 20220 Max. Watts/Amps 328/2.76 Volts: 120 / 60Hz Shutoff 22' 5" Dimensions (L x W x H) 10.5" x 4.5" x 7.75" Included Fittings: 1 1/2" Coupling, 2" Coupling, 2" to 1 1/2" Reducer, 1 1/2" Stepped Barb, 2" Stepped Barb, 1 1/2" Swivel Joint Connector |
|
6600 GPH – ITEM# 20230 Max. Watts/Amps 593/4.94 Volts: 120 / 60Hz Shutoff 30' 5" Dimensions (L x W x H) 10.5" x 4.5" x 7.75" Included Fittings: 1 1/2" Coupling, 2" Coupling, 2" to 1 1/2" Reducer, 1 1/2" Stepped Barb, 2" Stepped Barb, 1 1/2" Swivel Joint Connector | 7600 GPH – ITEM# 20235 Max. Watts/Amps 660/5.5 Volts: 120 / 60Hz Shutoff 27' 5" Dimensions (L x W x H) 10.5" x 4.5" x 7.75" Included Fittings: 1 1/2" Coupling, 2" Coupling, 2" to 1 1/2" Reducer, 1 1/2" Stepped Barb, 2" Stepped Barb, 1 1/2" Swivel Joint Connector |
PM NAME | PM ITEM# | Watts | Flow at 1' | Flow at 3' | Flow at 5' | Flow at 7' | Flow at 10' | Flow at 15' | Flow at 20' | Flow at 25' | Flow at 30' | Shut-Off (Feet) |
PMHD 1900 | 20210 | 93 | 1710 | 1325 | 870 | 555 | - | - | - | - | - | 10' |
PMHD 2550 | 20215 | 147 | 2380 | 2010 | 1490 | 1045 | 455 | - | - | - | - | 11' 5" |
PMHD 4850 | 20220 | 328 | 4725 | 4300 | 3700 | 3050 | 2225 | 1550 | 300 | - | - | 22' 5" |
PMHD 6100 | 20225 | 520 | 5750 | 4725 | 4175 | 3450 | 2400 | 1625 | 850 | 250 | - | 28' |
PMHD 6600 | 20230 | 593 | 6525 | 6275 | 5500 | 4925 | 4325 | 3325 | 2425 | 1850 | 550 | 30' 5" |
PMHD 7600 | 20235 | 660 | 7440 | 7210 | 6690 | 6170 | 5525 | 3805 | 2640 | 1310 | - | 27' 5" |
@@@@@@
Manuals
( 2.35 MB)
@@@@@@
@@@@@@
Replacement Part
